INGCO 45KN Hydraulic Cable Crimper Tool Kit ($4\text{–}70\text{mm}^2$ Cu Capacity, 4.5-Ton Hydraulic Force, 9 Hexagonal Crimping Dies Included, 11mm Stroke, Heavy-Duty BMC Blow-Molded Storage Case)
Eliminate loose cable lugs, high electrical resistance, and burnt-out terminal posts caused by crushing battery cables with hammers or inefficient mechanical pliers. The INGCO HHCT0170 Hydraulic Cable Crimper completely replaces cumbersome manual ratcheting crimpers that require immense physical exertion and deliver uneven compression. By multiplying your hand effort into 45KN of smooth hydraulic pressure, this compact 310mm tool forces heavy copper lugs and terminal sleeves into a tight, solid hexagonal block for maximum ampacity and structural safety.
45KN Hydraulic Force Output & $4\text{–}70\text{mm}^2$ Copper Range
45KN ($4.5\text{ Tons}$) High-Pressure Hydraulic Ram: Engineered with an internal hydraulic fluid circuit that generates $4.5\text{ Tons}$ of force at the die head. Effortlessly compresses thick copper terminal lugs with minimal operator hand effort.
$4\text{mm}^2$ to $70\text{mm}^2$ Versatile Crimping Range: Designed specifically for copper (Cu) cable terminations, making it the ideal compression tool for everything from standard electrical panel wiring to heavy industrial battery cables and main power feeds.
$11\text{mm}$ Ram Stroke Travel: Features an optimized $11\text{mm}$ ram stroke that opens wide enough for rapid lug loading while maintaining a fast pumping cycle to complete crimps in seconds.
Precision Hexagonal Dies & Compact Ergonomic Build
9 Precision Hardened Steel Hexagon Dies: Includes a comprehensive set of 9 interchangeable steel dies ($4, 6, 8, 10, 16, 25, 35, 50, \text{and } 70\text{mm}^2$). The hexagonal die shape compresses lugs uniformly from all 6 sides, purging internal air gaps to ensure zero voltage drop and high pull-out resistance.
1.80kg Lightweight & Compact $310\text{mm}$ Frame: Forged with a compact $310\text{mm}$ structural length and weighing only $1.80\text{kg}$, allowing electricians to easily operate the tool inside cramped junction boxes, control panels, and under-hood vehicle setups.
Rotatable Head & On/Off Pressure Release Valve: Outfitted with an easy-turn pressure release valve to instantly retract the dies after crimping, paired with a rotatable head structure for comfortable angling in tight corners.
Product Specifications:
Copper Cable Crimping Capacity Range: $4\text{mm}^2$ to $70\text{mm}^2$ (Cu)
Maximum Output Hydraulic Force: 45 KN ($4.5\text{ Metric Tons}$)
Crimping Profile Geometry: Uniform Hexagon Compression
Hydraulic Ram Stroke Distance: 11 mm
Bare Tool Overall Length: Approx. 310 mm
Bare Tool Net Weight: Approx. 1.80 kg
Storage Case Gross Weight: 1.10 kg (Total Kit Weight: ~2.90 kg)
Included Accessories Set: 9 x Hex Crimping Dies ($4, 6, 8, 10, 16, 25, 35, 50, 70\text{mm}^2$), 1 x Spare Sealing O-Ring Set
Packaging Layout: Fully organized inside an authentic, branded Blow-Molded Case (BMC).
Best Use Cases
Commercial Electrical Panel Building & Mains Wiring: The absolute daily baseline crimping asset for electricians and panel builders in Salem to terminate heavy main distribution lines, busbar connections, and industrial breaker lugs cleanly.
Solar Power Inverter & Heavy Battery Bank Wiring: Perfect for solar installers and auto electricians to compress heavy-gauge battery interconnect cables, solar inverter feeds, and winch power leads securely.
Pencil Carving Art Studio Machinery & High-Power Control Wiring: A valuable studio utility asset for pencil carving artists setting up custom high-power workshop equipment or gallery lighting rigs. This hydraulic crimper ensures all custom electrical panel connections, heavy transformer lines, and machinery control boxes are safely terminated with zero electrical resistance.
Industrial Plant Maintenance & Utility Infrastructure: An indispensable utility carry for factory maintenance teams to perform rapid emergency cable splicing, motor terminal replacement, and ground lug compression on production lines.
TK Pro Tip: A hydraulic crimper delivers immense mechanical force, and selecting the exact matching die size for your lug is the absolute secret to achieving a perfect cold-welded joint without flash burrs or under-crimping! Always match the stamped size on your copper lug (e.g., $35\text{mm}^2$) with the corresponding die number in the kit. Slide the lug into the open die head, close the hydraulic release valve, and pump the handle steadily until the two die halves meet completely—you will feel a firm stop. Once the die faces touch, immediately open the pressure release valve to retract the ram; never over-force the handle beyond the contact point, as this preserves the internal hydraulic seals and keeps your die edges clean for life!
The TK Tools Promise
Verified: 100% original, factory-authentic INGCO hydraulic equipment—sourced directly and verified for true 45KN hydraulic pressure parameters, exact $4\text{–}70\text{mm}^2$ die accuracy, and authentic BMC packaging metrics.
Hydraulic Seal & Pressure Bench Check: Because electrical connections demand complete safety and mechanical integrity, our dedicated technical team in Salem manually unboxes every single kit, tests the hydraulic ram cycle under pressure, inspects all 9 die pairs for exact dimensional tolerances, and verifies the release valve mechanism and O-ring seals before approving the BMC for final warehouse dispatch to guarantee an elite, leak-free crimping system right out of the case.
Fast Delivery: Wrapped securely inside custom shock-absorbent multi-layer cushioning and shipped rapidly from our main central facility straight to your workshop counter, retail store desk, or commercial job site.
